Completely unrelated to boatbuilding... had a chance to take the family to see Joe Satriani at the Fox Theatre in Oakland the other night. Satriani is one of the best players around and its always a blast to see him do his thing. At the end of the show Sammy Hagar made a guest appearance for the encore. Great show. Back to boat stuff... spent a few "after work" hours starting to plumb the fuel system. The big manifold is the tank fill distribution, fed by a single deck fill behind the wheelhouse. The 1 1/2" hoses drop to the hard piping leading to the six fuel tanks. The smaller manifold below is the supply from the six tanks. Fuel transfer pumps (electric and manual back-up) will be mounted in between the two manifolds on the bulkhead. When its all hooked up, we'll be able to transfer from any tank to the day tank, or from tank to tank as needed for trim or fuel polishing. Thanks again to Chuck for all the aeroquip fittings and the lesson on making up the hoses.
Hi
ReplyDeleteOn the last picture there is a tank . Is that the day tank for the ship .
Your's
Jacques
Jacques,
ReplyDeleteYes thats a 50 gallon day tank. In normal operation, we will transfer from the main tanks, through racor, and into the day tank to feed the machinery.
Peter
